FAQ: What type of assay is the Gentian Calprotectin Immunoassay GCAL®?

What type of assay is GCAL®?

In our Frequently Asked Questions about calprotectin series we will answer questions we often receive about plasma and serum calprotectin and the Gentian Calprotectin Immunoassay GCAL®. If you have any additional questions don't hesitate to contact us on marketing@gentian.com.

In this section we will explain what type of assay the Gentian Calprotectin Immunoassay GCAL® is and what the advantages of this assay are.


Quantitative analysis of total calprotectin in blood sample

The Gentian Calprotectin Immunoassay (GCAL®) is an in vitro diagnostic product for the quantitative determination of calprotectin in human lithium heparin plasma and serum samples. The measurement of calprotectin in lithium heparin plasma and serum is used in the assessment  of inflammation.

  • CE-marked since 2017
  • IVDR registration in progress
  • Developed and manufactured by Gentian
  • Manufactured according to ISO 13485:2016


What is the assay principle for GCAL®

GCAL® is the first and only Particle-Enhanced Turbidimetric Immunoassay (PETIA) on multiple platforms for in vitro diagnostic testing of calprotectin in human plasma and serum samples. The use of avian antibodies provides the advantage of less interference and cross-reaction from human samples, thereby decreasing backgrounds levels and increasing sensitivity. The assay is rapidly performed in only 10 minutes and can be applied on a wide range of clinical chemistry analysers, including but not limited to:

What are the advantages of an open channel turbidimetric immunoassay?

GCAL® is an immunoassay applied to turbidimetry-based clinical chemistry platforms. Gentian has experience in nano-particle technology, converting classical immunoassays to the clinical chemistry platforms while maintaining high sensitivity and accuracy. Switching to clinical chemistry from manual systems, like ELISA, or lower throughput immunoassays, this enables the laboratory to increase work-flow efficiency and productivity, decreases manual work and thereby reduces time and costs. Moreover, the random access and short assay time allows a fast time to result providing rapid answers in critical patient care.

GCAL® is an open channel assay, meaning it can be added to all clinical chemistry analysers. Diagnostic laboratories are thereby not limited to the use of one specific instrument offering calprotectin but can apply GCAL® on their available instrumentation and thereby fill the open menu gaps.


How is the calibrator standardised?

The calibrator for the Gentian Calprotectin Immunoassay GCAL® is available as a 6-point pre-diluted calibrator kit. The calibrator is established according to section 5.6 in ISO 17511:2003. To date no international standard for serum and plasma calprotectin is available. The Gentian Calprotectin Calibrator is traceable via a published value transfer protocol1 to a highly pure recombinant calprotectin solution with assigned value by total protein determination by UV280 and known extinction coefficient.


What are the technical specifications?


Gentian Calprotectin Immunoassay Performance
Sample type Li-Heparin plasma, Serum
Assay type  PETIA
Format  Liquid reagents, ready to use
Precision (sample >1 mg/L) Total CV 4.0%
LoQ*  0.3 mg/L
Security zone*  Up to 95 mg/L
Measuring range*  0.4 - 20 mg/L
Calibration stability*  4 weeks

*Instrument dependent results achieved on Architect c4000 during validation.


Product range


Product no. Products Content
1201 Gentian Calprotectin Reagent Kit R1 54 mL + R2 9 mL
1202 Gentian Calprotectin Reagent Kit S R1 30 mL + R2 5 mL
1219 Gentian Calprotectin Control Kit 2 x 1 mL
1251 Gentian Calprotectin Calibrator Kit 6 x 1 mL



Why choose the Gentian Calprotectin GCAL® Immunoassay?


Contact us

For more details about the Gentian Calprotectin Immunoassay GCAL®  please contact us at marketing@gentian.com or fill out the form below:


Explore other FAQ about plasma and serum calprotectin

What is calprotectin’s role in neutrophil activation?

What is the clinical value of calprotectin in sepsis & severe infections?

What is the value of calprotectin in blood as biomarker in IBD?

Is calprotectin upregulated in sepsis in COVID-19?

What role can plasma & serum calprotectin play in severe COVID-19?

How is calprotectin useful to monitor treatment response in rheumatoid arthritis?

How is calprotectin useful in clinical assessment of rheumatoid arthritis?



  1. Blirup-Jensen S et al. IFCC Committee on Plasma Proteins. Protein standardization V: value transfer. A practical protocol for the assignment of serum protein values from a Reference Material to a Target Material. Clin Chem Lab Med. 2008
